Rv3692 (moxR2)

Current annotations:
- TBCAP: (community-based annotations - see table at bottom of page)
- TBDB: MoxR-like ATPase
- REFSEQ: methanol dehydrogenase transcriptional regulatory protein MOXR2
- PATRIC: MoxR-like ATPase
- TUBERCULIST: Probable methanol dehydrogenase transcriptional regulatory protein MoxR2
- NCBI: Probable methanol dehydrogenase transcriptional regulatory protein MoxR2
- updated information (H37Rv4):
  - gene name: moxR2
  - function:
  - reference:
Type: Not Target
Start: 4133516
End: 4134592
Operon:

Trans-membrane region:
Role: I.J.1 - Repressors/activators
GO terms:
- GO:0016887 - ATPase activity (Uniprot)
- GO:0005618 - cell wall (Uniprot)
- GO:0005524 - ATP binding (Uniprot)
Reaction(s) (based on iSM810 metabolic model):
Gene Expression Profile (Transcriptional Responses to Drugs; Boshoff et al, 2004)
Gene Modules extracted from cluster analysis of 249 transcriptomic datasets using ICA
Orthologs among selected mycobacteria
Protein structure:
Search for Homologs in PDB
Top 10 Homologs in PDB (as of Nov 2020):

PDB aa ident species PDB title

2R44 40% Cytophaga hutchinsonii ATCC 33406 CRYSTAL STRUCTURE OF A PUTATIVE ATPASE (CHU_0153) FROM CYTOPHAGA HUTCHINSONII ATCC 33406 AT 2.00 A RESOLUTION
Links to additional information on moxR2:
- TBDB (updated)
- Phyre2 structure prediction, model: final.casp.pdb (from Mao et al, 2013)
- UniProt
- AlphaFold model
- Vulnerability = 1.238 (from Jeremy Rock's lab)
- KEGG - nucleotide and amino acid sequences of gene
- Mycobrowser
- PATRIC
- BioCyc
- Systems Biology

PDB	aa ident	species	PDB title
2R44	40%	Cytophaga hutchinsonii ATCC 33406	CRYSTAL STRUCTURE OF A PUTATIVE ATPASE (CHU_0153) FROM CYTOPHAGA HUTCHINSONII ATCC 33406 AT 2.00 A RESOLUTION

Amino Acid Sequence

VTQSASNPQAPPTQTPGAELPGYPPQAGGAPTAAPSGPHPHRAEAESARDALLALRAEVAKAVVGQDGVISGLVIALLCRGHVLLEGVPGVAKTLIVRAM
SAALQLEFKRVQFTPDLMPGDVTGSLVYDARTAEFVFRPGPVFTNLLLADEINRTPPKTQAALLEAMEERQVSVEGEPKPLPNPFIVAATQNPIEYEGTY
QLPEAQLDRFLLKLNVTLPARDSEIAILDRHAHGFDPRDLSAINPVAGPAELAAGREAVRHVLVANEVLGYIVDIVGATRSSPALQLGVSPRGATALLGT
ARSWAWLSGRDYVTPDDVKAMARPTLRHRVMLRPEAELEGATPDGVLDGILASVPVPR

(Nucleotide sequence available on KEGG)

Additional Information

ESSENTIALITY

MtbTnDB - interactive tool for exploring a database of published TnSeq datasets for Mtb

TnSeqCorr - genes with correlated TnSeq profiles across >100 conditions *new*

Classification	Condition	Strain	Method	Reference	Notes
Non-Essential	Sodium Oleate	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 15 sites
Non-Essential	Lignoceric Acid	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 15 sites
Non-Essential	Phosphatidylcholine	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 15 sites
Non-Essential	minimal media + 0.1% glycerol	H37RvMA	Gumbel	Griffin et al. (2011)	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 16 sites
Non-Essential	minimal media + 0.01% cholesterol	H37RvMA	Gumbel	Griffin et al. (2011)	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 16 sites
Non-Essential	7H10-glycerol	H37RvMA	TraSH	Sassetti et al. (2003a)
Non-Essential	C57BL/6J mice (8 weeks)	H37RvMA	TraSH	Sassetti et al. (2003b)	Hybridization Ratio: 0.47
Non-Essential	7H09/7H10 + rich media	H37RvMA	MotifHMM	DeJesus et al. (2017)	Fully saturated (14 reps).

TnSeq Data No data currently available.

No TnSeq data currently available for this Target.

RNASeq Data No data currently available.

No RNA-Seq data currently available for this Target.

Metabolomic Profiles No data currently available.

No Metabolomic data currently available for this Target.

Proteomic Data No data currently available.

No Proteomic data currently available for this Target.

Regulatory Relationships from Systems Biology

BioCyc

Gene interactions based on ChIPSeq and Transcription Factor Over-Expression (TFOE) (Systems Biology)

NOTE: Green edges represent the connected genes being classified as differentially essential as a result of the middle gene being knocked out. These interactions are inferred based on RNASeq.

Interactions based on ChIPSeq data

Binds To:
Bound By:
- Rv0023 (-)
- Rv1049 (-)

Interactions based on ChIPSeq data (Minch et al. 2014)

Binds To:
- No bindings to other targets were found.
Bound By:
- Rv3574 (kstR) (Direct binding)
- Rv3249c (-) (Upstream of operon)

Interactions based on TFOE data (Rustad et al. 2014)

Upregulates:
- Does not upregulate other genes.
Upregulated by:
- Not upregulated by other genes.
Downregulates:
- Does not downregulate other genes.
Downregulated by:
- Rv0023 (-)
- Rv1049 (-)

TBCAP

Tubculosis Community Annotation Project (

Slayden et al., 2013

Rv3692 (moxR2)

Property	Value	Creator	Evidence	PMID	Comment
Interaction	Transcription Rv3223c	aparna.vchalam	NAS		S. Mehra & D. Kaushal Functional genomics reveals extended roles of the Mycobacterium tuberculosis stress response factor sigmaH. J. Bacteriol. 2009
Citation	Functional genomics reveals extended roles of the Mycobacterium tuberculosis stress response factor sigmaH. S. Mehra & D. Kaushal J. Bacteriol. 2009	priyadarshinipriyanka2001	NAS	19376862	None
Interaction	Transcription Rv3223c	priyadarshinipriyanka2001	NAS		S. Mehra & D. Kaushal Functional genomics reveals extended roles of the Mycobacterium tuberculosis stress response factor sigmaH. J. Bacteriol. 2009
Citation	Functional genomics reveals extended roles of the Mycobacterium tuberculosis stress response factor sigmaH. S. Mehra & D. Kaushal J. Bacteriol. 2009	aparna.vchalam	NAS	19376862	None
Interaction	Regulatory Rv2939	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2939	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2935	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2935	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2934	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2934	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2933	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2933	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2932	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2932	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2931	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2931	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2930	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2930	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3133c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3134c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2937	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2938	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2939	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3132c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2933	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2934	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2935	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2936	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1094	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2930	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2931	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2932	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Property

Value

Creator

Evidence

PMID

Comment

Interaction

Transcription Rv3223c

aparna.vchalam

NAS

S. Mehra & D. Kaushal Functional genomics reveals extended roles of the Mycobacterium tuberculosis stress response factor sigmaH. J. Bacteriol. 2009

Citation

Functional genomics reveals extended roles of the Mycobacterium tuberculosis stress response factor sigmaH. S. Mehra & D. Kaushal J. Bacteriol. 2009

priyadarshinipriyanka2001

NAS

19376862

None

Interaction

Transcription Rv3223c

priyadarshinipriyanka2001

NAS

S. Mehra & D. Kaushal Functional genomics reveals extended roles of the Mycobacterium tuberculosis stress response factor sigmaH. J. Bacteriol. 2009

Citation

Functional genomics reveals extended roles of the Mycobacterium tuberculosis stress response factor sigmaH. S. Mehra & D. Kaushal J. Bacteriol. 2009

aparna.vchalam

NAS

19376862

None

Interaction

Regulatory Rv2939

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2939

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2935

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2935

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2934

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2934

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2933

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2933

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2932

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2932

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2931

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2931

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2930

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2930

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3133c

yamir.moreno

IDA

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3134c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2937

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2938

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2939

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3132c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2933

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2934

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2935

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2936

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1094

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2930

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2931

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2932

yamir.moreno

IDA

Comments
