Rv3416 (whiB3)

Current annotations:
- TBCAP: (community-based annotations - see table at bottom of page)
- TBDB: transcriptional regulator whib-like whiB3
- REFSEQ: transcriptional regulatory protein WHIB-like WHIB3
- PATRIC: Sporulation regulatory protein WhiD
- TUBERCULIST: Transcriptional regulatory protein WhiB-like WhiB3. Contains [4FE-4S] cluster.
- NCBI: Transcriptional regulatory protein WhiB-like WhiB3 Contains [4FE-4S] cluster
- updated information (H37Rv4):
  - gene name: whiB3
  - function:
  - reference:
Type: Not Target
Start: 3834892
End: 3835200
Operon:

Trans-membrane region:
Role: I.J.1 - Repressors/activators
GO terms:
- GO:1902882 - regulation of response to oxidative stress (Uniprot)
- GO:0090034 - regulation of chaperone-mediated protein complex assembly (Uniprot)
- GO:0071766 - Actinobacterium-type cell wall biogenesis (Uniprot)
- GO:0055114 - oxidation-reduction process (Uniprot)
- GO:0051539 - 4 iron, 4 sulfur cluster binding (Uniprot)
- GO:0051536 - iron-sulfur cluster binding (Uniprot)
- GO:0046872 - metal ion binding (Uniprot)
- GO:0045454 - cell redox homeostasis (Uniprot)
- GO:0019217 - regulation of fatty acid metabolic process (Uniprot)
- GO:0019216 - regulation of lipid metabolic process (Uniprot)
- GO:0015035 - protein disulfide oxidoreductase activity (Uniprot)
- GO:0009405 - pathogenesis (Uniprot)
- GO:0006355 - regulation of transcription, DNA-templated (Uniprot)
- GO:0006351 - transcription, DNA-templated (Uniprot)
- GO:0005737 - cytoplasm (Uniprot)
- GO:0005618 - cell wall (Uniprot)
- GO:0005515 - protein binding (Uniprot)
- GO:0003677 - DNA binding (Uniprot)
Reaction(s) (based on iSM810 metabolic model):
Gene Expression Profile (Transcriptional Responses to Drugs; Boshoff et al, 2004)
Gene Modules extracted from cluster analysis of 249 transcriptomic datasets using ICA
Orthologs among selected mycobacteria
Protein structure:
Search for Homologs in PDB

Top 10 Homologs in PDB (as of Nov 2020):

PDB	aa ident	species	PDB title
6ONU	44%	Mycobacterium tuberculosis H37Rv	Complex structure of WhiB1 and region 4 of SigA in P21 space group.
6ONO	44%	Mycobacterium tuberculosis H37Rv	Complex structure of WhiB1 and region 4 of SigA in C2221 space group
5OAY	44%	Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)	M. tuberculosis [4Fe-4S] protein WhiB1 is a four-helix bundle that forms a NO-sensitive complex with sigmaA and regulates the major virulence factor ESX-1

Links to additional information on whiB3:
- KEGG - nucleotide and amino acid sequences of gene
- Mycobrowser
- PATRIC
- TBDB (updated)
- Phyre2 structure prediction, model: final.casp.pdb (from Mao et al, 2013)
- UniProt
- AlphaFold model
- Vulnerability = -0.205 (from Jeremy Rock's lab)
- BioCyc
- Systems Biology

Amino Acid Sequence

MPQPEQLPGPNADIWNWQLQGLCRGMDSSMFFHPDGERGRARTQREQRAKEMCRRCPVIEACRSHALEVGEPYGVWGGLSESERDLLLKGTMGRTRGIRR
TA

(Nucleotide sequence available on KEGG)

Additional Information

ESSENTIALITY

MtbTnDB - interactive tool for exploring a database of published TnSeq datasets for Mtb

TnSeqCorr - genes with correlated TnSeq profiles across >100 conditions *new*

Classification	Condition	Strain	Method	Reference	Notes
Non-Essential	Sodium Oleate	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.000000; 1 non-insertions in a row out of 4 sites
Non-Essential	Lignoceric Acid	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.000000; 1 non-insertions in a row out of 4 sites
Non-Essential	Phosphatidylcholine	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.000000; 0 non-insertions in a row out of 4 sites
Non-Essential	minimal media + 0.1% glycerol	H37RvMA	Gumbel	Griffin et al. (2011)	Probability of Essentiality: 0.000000; 0 non-insertions in a row out of 5 sites
Non-Essential	minimal media + 0.01% cholesterol	H37RvMA	Gumbel	Griffin et al. (2011)	Probability of Essentiality: 0.000150; 2 non-insertions in a row out of 5 sites
Non-Essential	7H10-glycerol	H37RvMA	TraSH	Sassetti et al. (2003a)
Non-Essential	C57BL/6J mice (8 weeks)	H37RvMA	TraSH	Sassetti et al. (2003b)	Hybridization Ratio: 0.77
Non-Essential	7H09/7H10 + rich media	H37RvMA	MotifHMM	DeJesus et al. (2017)	Fully saturated (14 reps).

TnSeq Data No data currently available.

No TnSeq data currently available for this Target.

RNASeq Data No data currently available.

No RNA-Seq data currently available for this Target.

Metabolomic Profiles No data currently available.

No Metabolomic data currently available for this Target.

Proteomic Data No data currently available.

No Proteomic data currently available for this Target.

Regulatory Relationships from Systems Biology

BioCyc

Gene interactions based on ChIPSeq and Transcription Factor Over-Expression (TFOE) (Systems Biology)

NOTE: Green edges represent the connected genes being classified as differentially essential as a result of the middle gene being knocked out. These interactions are inferred based on RNASeq.

Interactions based on ChIPSeq data

Interactions based on ChIPSeq data (Minch et al. 2014)

Binds To:
- Rv0095c (-) (Direct binding)
- Rv0167 (yrbE1A) (Direct binding)
- Rv0219 (-) (Direct binding)
- Rv0950c (-) (Direct binding)
- Rv2136c (-) (Direct binding)
- Rv2137c (-) (Direct binding)
- Rv2138 (lppL) (Direct binding)
- Rv3686c (-) (Direct binding)
- Rv0168 (yrbE1B) (Upstream of operon)
- Rv0169 (mce1A) (Upstream of operon)
- Rv0170 (mce1B) (Upstream of operon)
- Rv0171 (mce1C) (Upstream of operon)
- Rv0172 (mce1D) (Upstream of operon)
- Rv0173 (lprK) (Upstream of operon)
- Rv0174 (mce1F) (Upstream of operon)
- Rv0175 (-) (Upstream of operon)
- Rv0176 (-) (Upstream of operon)
- Rv0177 (-) (Upstream of operon)
- Rv0178 (-) (Upstream of operon)
- Rv2135c (-) (Upstream of operon)
- Rv3685c (cyp137) (Upstream of operon)
Bound By:
- Rv0047c (-) (Direct binding)
- Rv0273c (-) (Direct binding)
- Rv3849 (espR) (Direct binding)

Interactions based on TFOE data (Rustad et al. 2014)

TBCAP

Tubculosis Community Annotation Project (

Slayden et al., 2013

Rv3416 (whiB3)

Property	Value	Creator	Evidence	PMID	Comment
Interaction	Regulatory Rv2703	chirupolo	IPI		Affinity purification (Physical interaction) B. Hutter & T. Dick Molecular genetic characterisation of whiB3, a mycobacterial homologue of a Streptomyces sporulation factor. Res. Microbiol. 1999
Citation	Mycobacterium tuberculosis WhiB3 interacts with RpoV to affect host survival but is dispensable for in vivo growth. AJ. Steyn, DM. Collins et al. Proc. Natl. Acad. Sci. U.S.A. 2002	chirupolo	IPI	11880648	Affinity purification (Physical interaction)
Interaction	Regulatory Rv2703	chirupolo	IPI		Affinity purification (Physical interaction) AJ. Steyn, DM. Collins et al. Mycobacterium tuberculosis WhiB3 interacts with RpoV to affect host survival but is dispensable for in vivo growth. Proc. Natl. Acad. Sci. U.S.A. 2002
Citation	Molecular genetic characterisation of whiB3, a mycobacterial homologue of a Streptomyces sporulation factor. B. Hutter & T. Dick Res. Microbiol. 1999	chirupolo	IPI	10422690	Yeast two-hybrid (Physical interaction)
Interaction	Regulatory Rv2703	chirupolo	IPI		Yeast two-hybrid (Physical interaction) B. Hutter & T. Dick Molecular genetic characterisation of whiB3, a mycobacterial homologue of a Streptomyces sporulation factor. Res. Microbiol. 1999
Citation	Mycobacterium tuberculosis WhiB3 interacts with RpoV to affect host survival but is dispensable for in vivo growth. AJ. Steyn, DM. Collins et al. Proc. Natl. Acad. Sci. U.S.A. 2002	chirupolo	IPI	11880648	Yeast two-hybrid (Physical interaction)
Interaction	Regulatory Rv2703	chirupolo	IPI		Yeast two-hybrid (Physical interaction) AJ. Steyn, DM. Collins et al. Mycobacterium tuberculosis WhiB3 interacts with RpoV to affect host survival but is dispensable for in vivo growth. Proc. Natl. Acad. Sci. U.S.A. 2002
Citation	Molecular genetic characterisation of whiB3, a mycobacterial homologue of a Streptomyces sporulation factor. B. Hutter & T. Dick Res. Microbiol. 1999	chirupolo	IPI	10422690	Affinity purification (Physical interaction)
Interaction	Regulatory Rv2939	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2939	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2935	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2935	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2934	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2934	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2933	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2933	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2932	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2932	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2931	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2931	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2930	ashwinigbhat	IDA		One hybrid System M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Interaction	Regulatory Rv2930	ashwinigbhat	IDA		One hybrid System DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005
Interaction	Regulatory Rv2703	priyadarshinipriyanka2001	IPI		Yeast two-hybrid (Physical interaction) authors,M. Gomez,L. Doukhan,G. Nair,I. Smith sigA is an essential gene in Mycobacterium smegmatis. Mol. Microbiol. 1998
Interaction	Regulatory Rv2703	priyadarshinipriyanka2001	IPI		Yeast two-hybrid (Physical interaction) AJ. Steyn, DM. Collins et al. Mycobacterium tuberculosis WhiB3 interacts with RpoV to affect host survival but is dispensable for in vivo growth. Proc. Natl. Acad. Sci. U.S.A. 2002
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2031c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3545c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3550	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3551	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3552	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3537	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3538	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3543c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3544c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3417c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3418c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3504	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3505	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2937	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2938	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2939	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3197A	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2933	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2934	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2935	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2936	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1912c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2930	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2931	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2932	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1908c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1909c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1910c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1911c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1464	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1465	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1466	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1907c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1460	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1461	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1462	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1463	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv0468	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv0469	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv0551c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv1094	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv0351	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv0352	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv0353	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv0467	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv0244c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv0350	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Property

Value

Creator

Evidence

PMID

Comment

Interaction

Regulatory Rv2703

chirupolo

IPI

Affinity purification (Physical interaction)
B. Hutter & T. Dick Molecular genetic characterisation of whiB3, a mycobacterial homologue of a Streptomyces sporulation factor. Res. Microbiol. 1999

Citation

Mycobacterium tuberculosis WhiB3 interacts with RpoV to affect host survival but is dispensable for in vivo growth. AJ. Steyn, DM. Collins et al. Proc. Natl. Acad. Sci. U.S.A. 2002

chirupolo

IPI

11880648

Affinity purification (Physical interaction)

Interaction

Regulatory Rv2703

chirupolo

IPI

Affinity purification (Physical interaction)
AJ. Steyn, DM. Collins et al. Mycobacterium tuberculosis WhiB3 interacts with RpoV to affect host survival but is dispensable for in vivo growth. Proc. Natl. Acad. Sci. U.S.A. 2002

Citation

Molecular genetic characterisation of whiB3, a mycobacterial homologue of a Streptomyces sporulation factor. B. Hutter & T. Dick Res. Microbiol. 1999

chirupolo

IPI

10422690

Yeast two-hybrid (Physical interaction)

Interaction

Regulatory Rv2703

chirupolo

IPI

Yeast two-hybrid (Physical interaction)
B. Hutter & T. Dick Molecular genetic characterisation of whiB3, a mycobacterial homologue of a Streptomyces sporulation factor. Res. Microbiol. 1999

Citation

Mycobacterium tuberculosis WhiB3 interacts with RpoV to affect host survival but is dispensable for in vivo growth. AJ. Steyn, DM. Collins et al. Proc. Natl. Acad. Sci. U.S.A. 2002

chirupolo

IPI

11880648

Yeast two-hybrid (Physical interaction)

Interaction

Regulatory Rv2703

chirupolo

IPI

Yeast two-hybrid (Physical interaction)
AJ. Steyn, DM. Collins et al. Mycobacterium tuberculosis WhiB3 interacts with RpoV to affect host survival but is dispensable for in vivo growth. Proc. Natl. Acad. Sci. U.S.A. 2002

Citation

Molecular genetic characterisation of whiB3, a mycobacterial homologue of a Streptomyces sporulation factor. B. Hutter & T. Dick Res. Microbiol. 1999

chirupolo

IPI

10422690

Affinity purification (Physical interaction)

Interaction

Regulatory Rv2939

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2939

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2935

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2935

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2934

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2934

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2933

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2933

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2932

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2932

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2931

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2931

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2930

ashwinigbhat

IDA

One hybrid System
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Interaction

Regulatory Rv2930

ashwinigbhat

IDA

One hybrid System
DM. Collins, B. Skou et al. Generation of attenuated Mycobacterium bovis strains by signature-tagged mutagenesis for discovery of novel vaccine candidates. Infect. Immun. 2005

Interaction

Regulatory Rv2703

priyadarshinipriyanka2001

IPI

Yeast two-hybrid (Physical interaction)
authors,M. Gomez,L. Doukhan,G. Nair,I. Smith sigA is an essential gene in Mycobacterium smegmatis. Mol. Microbiol. 1998

Interaction

Regulatory Rv2703

priyadarshinipriyanka2001

IPI

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2031c

yamir.moreno

IDA

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3545c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3550

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3551

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3552

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3537

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3538

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3543c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3544c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3417c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3418c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3504

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3505

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2937

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2938

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2939

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3197A

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2933

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2934

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2935

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2936

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1912c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2930

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2931

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2932

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1908c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1909c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1910c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1911c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1464

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1465

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1466

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1907c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1460

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1461

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1462

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1463

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv0468

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv0469

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv0551c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv1094

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv0351

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv0352

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv0353

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv0467

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv0244c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv0350

yamir.moreno

IDA

Comments
