Rv3080c (pknK)

Current annotations:
- TBCAP: (community-based annotations - see table at bottom of page)
- TBDB: serine/threonine-protein kinase pknK
- REFSEQ: serine/threonine-protein kinase transcriptional regulatory protein
- PATRIC: Transcriptional activator of maltose regulon MalT
- TUBERCULIST: Serine/threonine-protein kinase transcriptional regulatory protein PknK (protein kinase K) (STPK K)
- NCBI: Serine/threonine-protein kinase transcriptional regulatory protein PknK (protein kinase K) (STPK K)
- updated information (H37Rv4):
  - gene name: pknK
  - function:
  - reference:
Type: Not Target
Start: 3442656
End: 3445988
Operon:

Trans-membrane region:
Role: I.J.3 - Serine-Threonine protein kinases and phosphoprotein phosphatases
GO terms:
- GO:0051090 - regulation of DNA binding transcription factor activity (Uniprot)
- GO:0046872 - metal ion binding (Uniprot)
- GO:0046777 - protein autophosphorylation (Uniprot)
- GO:0042802 - identical protein binding (Uniprot)
- GO:0016740 - transferase activity (Uniprot)
- GO:0016310 - phosphorylation (Uniprot)
- GO:0016301 - kinase activity (Uniprot)
- GO:0016020 - membrane (Uniprot)
- GO:0009405 - pathogenesis (Uniprot)
- GO:0006468 - protein phosphorylation (Uniprot)
- GO:0005886 - plasma membrane (Uniprot)
- GO:0005829 - cytosol (Uniprot)
- GO:0005737 - cytoplasm (Uniprot)
- GO:0005618 - cell wall (Uniprot)
- GO:0005576 - extracellular region (Uniprot)
- GO:0005524 - ATP binding (Uniprot)
- GO:0004674 - protein serine/threonine kinase activity (Uniprot)
- GO:0004672 - protein kinase activity (Uniprot)
- GO:0000166 - nucleotide binding (Uniprot)
Reaction(s) (based on iSM810 metabolic model):
Gene Expression Profile (Transcriptional Responses to Drugs; Boshoff et al, 2004)
Gene Modules extracted from cluster analysis of 249 transcriptomic datasets using ICA
Orthologs among selected mycobacteria
Protein structure:
Search for Homologs in PDB

Top 10 Homologs in PDB (as of Nov 2020):

PDB	aa ident	species	PDB title
6B2P	36%	Mycobacterium tuberculosis	Dual Inhibition of the Essential Protein Kinases A and B in Mycobacterium tuberculosis
5U94	36%	Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)	Crystal structure of the Mycobacterium tuberculosis PASTA kinase PknB in complex with the potential theraputic kinase inhibitor GSK690693.
3ORM	36%	Mycobacterium tuberculosis	Mycobacterium tuberculosis PknB kinase domain D76A mutant
3F69	36%	Mycobacterium tuberculosis	Crystal structure of the Mycobacterium tuberculosis PknB mutant kinase domain in complex with KT5720
2FUM	36%	Mycobacterium tuberculosis H37Rv	Catalytic domain of protein kinase PknB from Mycobacterium tuberculosis in complex with mitoxantrone
1O6Y	36%	MYCOBACTERIUM TUBERCULOSIS	Catalytic domain of PknB kinase from Mycobacterium tuberculosis
1MRU	36%	Mycobacterium tuberculosis	Intracellular Ser/Thr protein kinase domain of Mycobacterium tuberculosis PknB.
6I2P	36%	Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)	Crystal structure of the Mycobacterium tuberculosis PknB kinase domain (L33E mutant) in complex with its substrate GarA
3ORT	36%	Mycobacterium tuberculosis	Mycobacterium tuberculosis PknB kinase domain L33D mutant (crystal form 6)
3ORP	36%	Mycobacterium tuberculosis	Mycobacterium tuberculosis PknB kinase domain L33D mutant (crystal form 5)

Links to additional information on pknK:
- KEGG - nucleotide and amino acid sequences of gene
- Mycobrowser
- PATRIC
- BioCyc
- Systems Biology
- TBDB (updated)
- Phyre2 structure prediction, model: final.casp.pdb (from Mao et al, 2013)
- UniProt
- AlphaFold model
- Vulnerability = 1.053 (from Jeremy Rock's lab)

Amino Acid Sequence

MTDVDPHATRRDLVPNIPAELLEAGFDNVEEIGRGGFGVVYRCVQPSLDRAVAVKVLSTDLDRDNLERFLREQRAMGRLSGHPHIVTVLQVGVLAGGRPF
IVMPYHAKNSLETLIRRHGPLDWRETLSIGVKLAGALEAAHRVGTLHRDVKPGNILLTDYGEPQLTDFGIARIAGGFETATGVIAGSPAFTAPEVLEGAS
PTPASDVYSLGATLFCALTGHAAYERRSGERVIAQFLRITSQPIPDLRKQGLPADVAAAIERAMARHPADRPATAADVGEELRDVQRRNGVSVDEMPLPV
ELGVERRRSPEAHAAHRHTGGGTPTVPTPPTPATKYRPSVPTGSLVTRSRLTDILRAGGRRRLILIHAPSGFGKSTLAAQWREELSRDGAAVAWLTIDND
DNNEVWFLSHLLESIRRVRPTLAESLGHVLEEHGDDAGRYVLTSLIDEIHENDDRIAVVIDDWHRVSDSRTQAALGFLLDNGCHHLQLIVTSWSRAGLPV
GRLRIGDELAEIDSAALRFDTDEAAALLNDAGGLRLPRADVQALTTSTDGWAAALRLAALSLRGGGDATQLLRGLSGASDVIHEFLSENVLDTLEPELRE
FLLVASVTERTCGGLASALAGITNGRAMLEEAEHRGLFLQRTEDDPNWFRFHQMFADFLHRRLERGGSHRVAELHRRASAWFAENGYLHEAVDHALAAGD
PARAVDLVEQDETNLPEQSKMTTLLAIVQKLPTSMVVSRARLQLAIAWANILLQRPAPATGALNRFETALGRAELPEATQADLRAEADVLRAVAEVFADR
VERVDDLLAEAMSRPDTLPPRVPGTAGNTAALAAICRFEFAEVYPLLDWAAPYQEMMGPFGTVYAQCLRGMAARNRLDIVAALQNFRTAFEVGTAVGAHS
HAARLAGSLLAELLYETGDLAGAGRLMDESYLLGSEGGAVDYLAARYVIGARVKAAQGDHEGAADRLSTGGDTAVQLGLPRLAARINNERIRLGIALPAA
VAADLLAPRTIPRDNGIATMTAELDEDSAVRLLSAGDSADRDQACQRAGALAAAIDGTRRPLAALQAQILHIETLAATGRESDARNELAPVATKCAELGL
SRLLVDAGLA

(Nucleotide sequence available on KEGG)

Additional Information

ESSENTIALITY

MtbTnDB - interactive tool for exploring a database of published TnSeq datasets for Mtb

TnSeqCorr - genes with correlated TnSeq profiles across >100 conditions *new*

Classification	Condition	Strain	Method	Reference	Notes
Uncertain	Sodium Oleate	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.283600; 6 non-insertions in a row out of 32 sites
Uncertain	Lignoceric Acid	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.586650; 6 non-insertions in a row out of 32 sites
Uncertain	Phosphatidylcholine	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.647950; 6 non-insertions in a row out of 32 sites
Non-Essential	minimal media + 0.1% glycerol	H37RvMA	Gumbel	Griffin et al. (2011)	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 33 sites
Uncertain	minimal media + 0.01% cholesterol	H37RvMA	Gumbel	Griffin et al. (2011)	Probability of Essentiality: 0.016800; 2 non-insertions in a row out of 33 sites
No-Data	7H10-glycerol	H37RvMA	TraSH	Sassetti et al. (2003a)
Too-Short	C57BL/6J mice (8 weeks)	H37RvMA	TraSH	Sassetti et al. (2003b)	Hybridization Ratio: -1
Non-Essential	7H09/7H10 + rich media	H37RvMA	MotifHMM	DeJesus et al. (2017)	Fully saturated (14 reps).

TnSeq Data No data currently available.

No TnSeq data currently available for this Target.

RNASeq Data No data currently available.

No RNA-Seq data currently available for this Target.

Metabolomic Profiles No data currently available.

No Metabolomic data currently available for this Target.

Proteomic Data No data currently available.

No Proteomic data currently available for this Target.

Regulatory Relationships from Systems Biology

BioCyc

Gene interactions based on ChIPSeq and Transcription Factor Over-Expression (TFOE) (Systems Biology)

NOTE: Green edges represent the connected genes being classified as differentially essential as a result of the middle gene being knocked out. These interactions are inferred based on RNASeq.

Interactions based on ChIPSeq data

Binds To:
- No bindings to other targets were found.
Bound By:

Interactions based on ChIPSeq data (Minch et al. 2014)

Binds To:
- No bindings to other targets were found.
Bound By:
- No bindings to other targets were found.

Interactions based on TFOE data (Rustad et al. 2014)

Upregulates:
- Does not upregulate other genes.
Upregulated by:
Downregulates:
- Does not downregulate other genes.
Downregulated by:
- Not downregulated by other genes.

TBCAP

Tubculosis Community Annotation Project (

Slayden et al., 2013

Rv3080c (pknK)

Property	Value	Creator	Evidence	PMID	Comment
Interaction	Activation Rv3088	sourish10	IDA		Spectrophotometric P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009
Interaction	Activation Rv3088	sourish10	IDA		Structural Analysis P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009
Interaction	Activation Rv3085	sourish10	IDA		Spectrophotometric P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009
Interaction	Activation Rv3085	sourish10	IDA		Structural Analysis P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009
Interaction	Activation Rv3084	sourish10	IDA		Structural Analysis P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009
Interaction	Activation Rv3084	sourish10	IDA		Spectrophotometric P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009
Interaction	Activation Rv3083	priyadarshinipriyanka2001	IDA		Spectrophotometric P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009
Interaction	Activation Rv3083	priyadarshinipriyanka2001	IDA		Structural Analysis P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009
Citation	The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. P. Kumar, D. Kumar et al. J. Biol. Chem. 2009	priyadarshinipriyanka2001	IEP	19251699	Affinity purification (Physical interaction)
Interaction	Activation Rv3084	priyadarshinipriyanka2001	IEP		Affinity purification (Physical interaction) P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009
Interaction	Activation Rv3085	priyadarshinipriyanka2001	IEP		Affinity purification (Physical interaction) P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009
Interaction	Signaling Rv1354c	swetha.r	IPI		Yeast two-hybrid (Physical interaction) T. Cui, L. Zhang et al. Uncovering new signaling proteins and potential drug targets through the interactome analysis of Mycobacterium tuberculosis. BMC Genomics 2009
Interaction	RegulatedBy Rv3676	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Interaction	RegulatedBy Rv3291c	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1328	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1781c	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv2117	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1235	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1237	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1238	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Interaction	RegulatedBy Rv3676	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Interaction	RegulatedBy Rv3291c	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Interaction	Regulates Rv1238	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1328	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1781c	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv2117	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1235	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1237	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Property

Value

Creator

Evidence

PMID

Comment

Interaction

Activation Rv3088

sourish10

IDA

Spectrophotometric
P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009

Interaction

Activation Rv3088

sourish10

IDA

Structural Analysis
P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009

Interaction

Activation Rv3085

sourish10

IDA

Interaction

Activation Rv3085

sourish10

IDA

Interaction

Activation Rv3084

sourish10

IDA

Interaction

Activation Rv3084

sourish10

IDA

Interaction

Activation Rv3083

priyadarshinipriyanka2001

IDA

Interaction

Activation Rv3083

priyadarshinipriyanka2001

IDA

Citation

The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. P. Kumar, D. Kumar et al. J. Biol. Chem. 2009

priyadarshinipriyanka2001

IEP

19251699

Affinity purification (Physical interaction)

Interaction

Activation Rv3084

priyadarshinipriyanka2001

IEP

Affinity purification (Physical interaction)
P. Kumar, D. Kumar et al. The Mycobacterium tuberculosis protein kinase K modulates activation of transcription from the promoter of mycobacterial monooxygenase operon through phosphorylation of the transcriptional regulator VirS. J. Biol. Chem. 2009

Interaction

Activation Rv3085

priyadarshinipriyanka2001

IEP

Interaction

Signaling Rv1354c

swetha.r

IPI

Yeast two-hybrid (Physical interaction)
T. Cui, L. Zhang et al. Uncovering new signaling proteins and potential drug targets through the interactome analysis of Mycobacterium tuberculosis. BMC Genomics 2009

Interaction

RegulatedBy Rv3676

yamir.moreno

ISO

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008

Interaction

RegulatedBy Rv3291c

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1328

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1781c

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv2117

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1235

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1237

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1238

yamir.moreno

ISO

Interaction

RegulatedBy Rv3676

yamir.moreno

ISO

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006

Interaction

RegulatedBy Rv3291c

yamir.moreno

ISO

Interaction

Regulates Rv1238

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1328

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1781c

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv2117

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1235

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1237

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Comments
