Rv2359 (zur)

Current annotations:
- TBCAP: (community-based annotations - see table at bottom of page)
- TBDB: fur family transcriptional regulator ferric uptake regulator
- REFSEQ: ferric uptake regulation protein FURB
- PATRIC: Zinc uptake regulation protein ZUR
- TUBERCULIST: Probable zinc uptake regulation protein Zur
- NCBI: Probable zinc uptake regulation protein Zur
- updated information (H37Rv4):
  - gene name: zur
  - function: regulates expression of zinc transporter
  - reference: Lucarelli 2008; PMID: 19169435
Type: Not Target
Start: 2641650
End: 2642042
Operon:

Trans-membrane region:
Role: I.J.1 - Repressors/activators
GO terms:
- GO:0046872 - metal ion binding (Uniprot)
- GO:0045893 - positive regulation of transcription, DNA-templated (Uniprot)
- GO:0045892 - negative regulation of transcription, DNA-templated (Uniprot)
- GO:0042803 - protein homodimerization activity (Uniprot)
- GO:0032993 - protein-DNA complex (Uniprot)
- GO:0010043 - response to zinc ion (Uniprot)
- GO:0008270 - zinc ion binding (Uniprot)
- GO:0006355 - regulation of transcription, DNA-templated (Uniprot)
- GO:0006351 - transcription, DNA-templated (Uniprot)
- GO:0005886 - plasma membrane (Uniprot)
- GO:0005737 - cytoplasm (Uniprot)
- GO:0005515 - protein binding (Uniprot)
- GO:0003700 - DNA binding transcription factor activity (Uniprot)
- GO:0003677 - DNA binding (Uniprot)
- GO:0001217 - bacterial-type RNA polymerase transcriptional repressor activity, sequence-specific DNA binding (Uniprot)
- GO:0000976 - transcription regulatory region sequence-specific DNA binding (Uniprot)
Reaction(s) (based on iSM810 metabolic model):
Gene Expression Profile (Transcriptional Responses to Drugs; Boshoff et al, 2004)
Gene Modules extracted from cluster analysis of 249 transcriptomic datasets using ICA
Orthologs among selected mycobacteria
Protein structure: 2o03
Search for Homologs in PDB

Top 10 Homologs in PDB (as of Nov 2020):

PDB	aa ident	species	PDB title
2O03	100%	Mycobacterium tuberculosis	Crystal structure of FurB from M. tuberculosis- a Zinc uptake regulator
3MWM	61%	Streptomyces coelicolor	Graded expression of zinc-responsive genes through two regulatory zinc-binding sites in Zur
2W57	37%	VIBRIO CHOLERAE	Crystal structure of the Vibrio cholerae ferric uptake regulator (Fur) reveals structural rearrangement of the DNA-binding domains
5L0P	37%	Homo sapiens	Symmetry-based assembly of a two-dimensional protein lattice
2FU4	37%	Escherichia coli	Crystal Structure of the DNA binding domain of E.coli FUR (Ferric Uptake Regulator)

Links to additional information on zur:
- KEGG - nucleotide and amino acid sequences of gene
- Mycobrowser
- PATRIC
- BioCyc
- Systems Biology
- TBDB (updated)
- Phyre2 structure prediction, model: final.casp.pdb (from Mao et al, 2013)
- UniProt
- AlphaFold model
- Vulnerability = -2.034 (from Jeremy Rock's lab)

Amino Acid Sequence

MSAAGVRSTRQRAAISTLLETLDDFRSAQELHDELRRRGENIGLTTVYRTLQSMASSGLVDTLHTDTGESVYRRCSEHHHHHLVCRSCGSTIEVGDHEVE
AWAAEVATKHGFSDVSHTIEIFGTCSDCRS

(Nucleotide sequence available on KEGG)

Additional Information

ESSENTIALITY

MtbTnDB - interactive tool for exploring a database of published TnSeq datasets for Mtb

TnSeqCorr - genes with correlated TnSeq profiles across >100 conditions *new*

Classification	Condition	Strain	Method	Reference	Notes
Uncertain	Sodium Oleate	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.982800; 5 non-insertions in a row out of 5 sites
Essential	Lignoceric Acid	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.991650; 5 non-insertions in a row out of 5 sites
Essential	Phosphatidylcholine	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.995100; 5 non-insertions in a row out of 5 sites
Non-Essential	minimal media + 0.1% glycerol	H37RvMA	Gumbel	Griffin et al. (2011)	Probability of Essentiality: 0.000000; 3 non-insertions in a row out of 6 sites
Non-Essential	minimal media + 0.01% cholesterol	H37RvMA	Gumbel	Griffin et al. (2011)	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 6 sites
Non-Essential	7H10-glycerol	H37RvMA	TraSH	Sassetti et al. (2003a)
Non-Essential	C57BL/6J mice (8 weeks)	H37RvMA	TraSH	Sassetti et al. (2003b)	Hybridization Ratio: 0.53
Non-Essential	7H09/7H10 + rich media	H37RvMA	MotifHMM	DeJesus et al. (2017)	Fully saturated (14 reps).

TnSeq Data No data currently available.

No TnSeq data currently available for this Target.

RNASeq Data No data currently available.

No RNA-Seq data currently available for this Target.

Metabolomic Profiles No data currently available.

No Metabolomic data currently available for this Target.

Proteomic Data No data currently available.

No Proteomic data currently available for this Target.

Regulatory Relationships from Systems Biology

BioCyc

Gene interactions based on ChIPSeq and Transcription Factor Over-Expression (TFOE) (Systems Biology)

NOTE: Green edges represent the connected genes being classified as differentially essential as a result of the middle gene being knocked out. These interactions are inferred based on RNASeq.

Interactions based on ChIPSeq data

Binds To:
Bound By:

Interactions based on ChIPSeq data (Minch et al. 2014)

Binds To:
- Rv0106 (-) (Direct binding)
- Rv0280 (PPE3) (Direct binding)
- Rv0282 (eccA3) (Direct binding)
- Rv1117 (-) (Direct binding)
- Rv1386 (PE15) (Direct binding)
- Rv2058c (rpmB2) (Direct binding)
- Rv2059 (-) (Direct binding)
- Rv2990c (-) (Direct binding)
- Rv2991 (-) (Direct binding)
- Rv0281 (-) (Upstream of operon)
- Rv0283 (eccB3) (Upstream of operon)
- Rv0284 (eccC3) (Upstream of operon)
- Rv0285 (PE5) (Upstream of operon)
- Rv0286 (PPE4) (Upstream of operon)
- Rv1387 (PPE20) (Upstream of operon)
- Rv2055c (rpsR2) (Upstream of operon)
- Rv2056c (rpsN2) (Upstream of operon)
- Rv2057c (rpmG1) (Upstream of operon)
- Rv2060 (-) (Upstream of operon)
Bound By:
- Rv0081 (-) (Upstream of operon)
- Rv2250c (-) (Upstream of operon)
- Rv2324 (-) (Upstream of operon)

Interactions based on TFOE data (Rustad et al. 2014)

TBCAP

Tubculosis Community Annotation Project (

Slayden et al., 2013

Rv2359 (zur)

Property	Value	Creator	Evidence	PMID	Comment
Interaction	Regulatory Rv3020c	ilamathi.raja	IEP		Co-expression (Functional linkage) A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009
Interaction	Regulatory Rv3017c	ilamathi.raja	IEP		Co-expression (Functional linkage) authors,L. Majlessi,MJ. Rojas,P. Brodin,C. Leclerc CD8+-T-cell responses of Mycobacterium-infected mice to a newly identified major histocompatibility complex class I-restricted epitope shared by proteins of the ESAT-6 family. Infect. Immun. 2003
Interaction	Regulatory Rv3017c	ilamathi.raja	IEP		Co-expression (Functional linkage) NC. Gey Van Pittius, J. Gamieldien et al. The ESAT-6 gene cluster of Mycobacterium tuberculosis and other high G+C Gram-positive bacteria. Genome Biol. 2001
Interaction	Regulatory Rv3019c	ilamathi.raja	IEP		Co-expression (Functional linkage) RL. Skjt, I. Brock et al. Epitope mapping of the immunodominant antigen TB10.4 and the two homologous proteins TB10.3 and TB12.9, which constitute a subfamily of the esat-6 gene family. Infect. Immun. 2002
Interaction	Regulatory Rv3019c	ilamathi.raja	IEP		Co-expression (Functional linkage) A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009
Interaction	Regulatory Rv3020c	ilamathi.raja	IEP		Co-expression (Functional linkage) RL. Skjt, I. Brock et al. Epitope mapping of the immunodominant antigen TB10.4 and the two homologous proteins TB10.3 and TB12.9, which constitute a subfamily of the esat-6 gene family. Infect. Immun. 2002
Interaction	Regulatory Rv3017c	ilamathi.raja	IEP		Co-expression (Functional linkage) RL. Skjt, I. Brock et al. Epitope mapping of the immunodominant antigen TB10.4 and the two homologous proteins TB10.3 and TB12.9, which constitute a subfamily of the esat-6 gene family. Infect. Immun. 2002
Interaction	Regulatory Rv3017c	ilamathi.raja	IEP		Co-expression (Functional linkage) A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009
Interaction	Regulatory Rv3017c	ilamathi.raja	IEP		Co-expression (Functional linkage) A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Transcription Rv2358	jhum4u2006	IPI		Affinity purification (Physical interaction) F. Canneva, M. Branzoni et al. Rv2358 and FurB: two transcriptional regulators from Mycobacterium tuberculosis which respond to zinc. J. Bacteriol. 2005
Citation	Rv2358 and FurB: two transcriptional regulators from Mycobacterium tuberculosis which respond to zinc. F. Canneva, M. Branzoni et al. J. Bacteriol. 2005	jhum4u2006	IPI	16077132	Affinity purification (Physical interaction)
Interaction	Transcription Rv2358	jhum4u2006	IPI		Affinity purification (Physical interaction) F. Canneva, M. Branzoni et al. Rv2358 and FurB: two transcriptional regulators from Mycobacterium tuberculosis which respond to zinc. J. Bacteriol. 2005
Interaction	PhysicalInteraction Rv2057c	devensrcp	IEP		Physical interaction A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	PhysicalInteraction Rv2058c	shahanup86	IEP		Physical interaction authors,GA. Owen,B. Pascoe,D. Kallifidas,MS. Paget Zinc-responsive regulation of alternative ribosomal protein genes in Streptomyces coelicolor involves zur and sigmaR. J. Bacteriol. 2007
Interaction	PhysicalInteraction Rv2058c	shahanup86	IEP		Physical interaction A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Regulatory Rv2059	shahanup86	IDA		Co-expression (Functional linkage) A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Regulates Rv2055c	akankshajain.21	IEP		Co-expression (Functional linkage) A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	PhysicalInteraction Rv2056c	devensrcp	IEP		ChiP (Physical Interaction) A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	PhysicalInteraction Rv2056c	devensrcp	IEP		ChiP (Physical Interaction) authors,GA. Owen,B. Pascoe,D. Kallifidas,MS. Paget Zinc-responsive regulation of alternative ribosomal protein genes in Streptomyces coelicolor involves zur and sigmaR. J. Bacteriol. 2007
Interaction	PhysicalInteraction Rv2057c	devensrcp	IEP		Physical interaction authors,DJ. Beste,E. Laing,B. Bonde,C. Avignone-Rossa,ME. Bushell,JJ. McFadden Transcriptomic analysis identifies growth rate modulation as a component of the adaptation of mycobacteria to survival inside the macrophage. J. Bacteriol. 2007
Interaction	Transcription Rv1195	ahal4789	IDA		Band shift A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Transcription Rv1195	ahal4789	IDA		Band shift S. Denkin, S. Byrne et al. Gene expression profiling analysis of Mycobacterium tuberculosis genes in response to salicylate. Arch. Microbiol. 2005
Interaction	Regulatory Rv0634B	prabhakarsmail	ISO		Footprinting authors,GA. Owen,B. Pascoe,D. Kallifidas,MS. Paget Zinc-responsive regulation of alternative ribosomal protein genes in Streptomyces coelicolor involves zur and sigmaR. J. Bacteriol. 2007
Interaction	Regulatory Rv0634B	prabhakarsmail	ISO		Footprinting A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Regulatory Rv0634B	akankshajain.21	ISO		Footprinting authors,JH. Shin,SY. Oh,SJ. Kim,JH. Roe The zinc-responsive regulator Zur controls a zinc uptake system and some ribosomal proteins in Streptomyces coelicolor A3(2). J. Bacteriol. 2007
Interaction	Regulatory Rv0634B	akankshajain.21	ISO		Footprinting authors,GA. Owen,B. Pascoe,D. Kallifidas,MS. Paget Zinc-responsive regulation of alternative ribosomal protein genes in Streptomyces coelicolor involves zur and sigmaR. J. Bacteriol. 2007
Interaction	Regulatory Rv0634B	akankshajain.21	ISO		Footprinting A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Regulatory Rv0634B	prabhakarsmail	ISO		Footprinting authors,JH. Shin,SY. Oh,SJ. Kim,JH. Roe The zinc-responsive regulator Zur controls a zinc uptake system and some ribosomal proteins in Streptomyces coelicolor A3(2). J. Bacteriol. 2007
Interaction	Regulatory Rv0292	gaat3s	IGC		Gene Neighborhood (Functional linkage) A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Regulatory Rv0290	gaat3s	IGC		Gene Neighborhood (Functional linkage) A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009
Interaction	Regulatory Rv0290	gaat3s	IGC		Gene Neighborhood (Functional linkage) A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Regulatory Rv0292	gaat3s	IGC		Gene Neighborhood (Functional linkage) A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009
Interaction	Regulatory Rv0289	gaat3s	IGC		Gene Neighborhood (Functional linkage) A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009
Interaction	Regulatory Rv0289	gaat3s	IGC		Gene Neighborhood (Functional linkage) A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Regulatory Rv0284	gaat3s	IGC		Gene Neighborhood (Functional linkage) GM. Rodriguez, MI. Voskuil et al. ideR, An essential gene in mycobacterium tuberculosis: role of IdeR in iron-dependent gene expression, iron metabolism, and oxidative stress response. Infect. Immun. 2002
Interaction	Regulatory Rv0284	gaat3s	IGC		Gene Neighborhood (Functional linkage) A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Regulatory Rv0283	gaat3s	IGC		Gene Neighborhood (Functional linkage) GM. Rodriguez, MI. Voskuil et al. ideR, An essential gene in mycobacterium tuberculosis: role of IdeR in iron-dependent gene expression, iron metabolism, and oxidative stress response. Infect. Immun. 2002
Interaction	Regulatory Rv0283	gaat3s	IGC		Gene Neighborhood (Functional linkage) A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Regulatory Rv0284	gaat3s	IGC		Gene Neighborhood (Functional linkage) A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009
Interaction	Regulatory Rv0282	gaat3s	IDA		Band Shift A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009
Interaction	Regulatory Rv0283	gaat3s	IGC		Gene Neighborhood (Functional linkage) A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009
Interaction	Regulatory Rv0105c	akankshajain.21	IDA		Footprinting A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Regulatory Rv0105c	prabhakarsmail	IDA		Footprinting A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	RegulatedBy Rv2358	yamir.moreno	IDA		Electrophoretic mobility shift assays EMSA. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . LacZ-promoter fusion. expression levels of LacZ- regulated promoter fusion measured and compared between wild-type and trans-element mutation (knockout, over expression etc.). F. Canneva, M. Branzoni et al. Rv2358 and FurB: two transcriptional regulators from Mycobacterium tuberculosis which respond to zinc. J. Bacteriol. 2005
Interaction	RegulatedBy Rv2358	yamir.moreno	IEP		Electrophoretic mobility shift assays EMSA. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . LacZ-promoter fusion. expression levels of LacZ- regulated promoter fusion measured and compared between wild-type and trans-element mutation (knockout, over expression etc.). F. Canneva, M. Branzoni et al. Rv2358 and FurB: two transcriptional regulators from Mycobacterium tuberculosis which respond to zinc. J. Bacteriol. 2005
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv3612c	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv2990c	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv3020c	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv3022c	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv3229c	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	Regulates Rv2055c	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv2056c	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv2057c	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv2060	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. qRT-PCR. mRNA expression levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using qRT-PCR technique.
Interaction	Regulates Rv1857	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. qRT-PCR. mRNA expression levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using qRT-PCR technique. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. qRT-PCR. mRNA expression levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using qRT-PCR technique.
Interaction	Regulates Rv1857	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. qRT-PCR. mRNA expression levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using qRT-PCR technique. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv1870c	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0290	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0291	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0292	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv1195	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0287	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0288	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0289	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0283	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0284	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0285	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0286	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0232	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Citation	Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007	yamir.moreno	IEP	17098899	Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
Interaction	Regulates Rv0281	yamir.moreno	IEP		Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007
Interaction	RegulatedBy Rv3676	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Interaction	Regulates Rv3022c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv3215	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv3229c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv3612c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv3846	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv2990c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv3017c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv3019c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv3020c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv2060	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv2359	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Interaction	RegulatedBy Rv2359	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv2384	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv2794c	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Interaction	Regulates Rv2055c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv2056c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv2057c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv2058c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv2059	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv1857	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv1870c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1928c	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1945	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0291	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0292	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv1195	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1847	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Interaction	Regulates Rv0286	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0287	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0288	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0289	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0290	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0282	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0283	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0284	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0285	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0106	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0232	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0280	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0281	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Interaction	RegulatedBy Rv2358	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	TAS	18985025	Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
Interaction	Regulates Rv0105c	yamir.moreno	TAS		Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Interaction	RegulatedBy Rv3676	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Interaction	Regulates Rv3215	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv3846	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1945	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv2359	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Interaction	RegulatedBy Rv2359	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv2384	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv2794c	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1847	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1928c	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006

Property

Value

Creator

Evidence

PMID

Comment

Interaction

Regulatory Rv3020c

ilamathi.raja

IEP

Co-expression (Functional linkage)
A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009

Interaction

Regulatory Rv3017c

ilamathi.raja

IEP

Co-expression (Functional linkage)
authors,L. Majlessi,MJ. Rojas,P. Brodin,C. Leclerc CD8+-T-cell responses of Mycobacterium-infected mice to a newly identified major histocompatibility complex class I-restricted epitope shared by proteins of the ESAT-6 family. Infect. Immun. 2003

Interaction

Regulatory Rv3017c

ilamathi.raja

IEP

Co-expression (Functional linkage)
NC. Gey Van Pittius, J. Gamieldien et al. The ESAT-6 gene cluster of Mycobacterium tuberculosis and other high G+C Gram-positive bacteria. Genome Biol. 2001

Interaction

Regulatory Rv3019c

ilamathi.raja

IEP

Co-expression (Functional linkage)
RL. Skjt, I. Brock et al. Epitope mapping of the immunodominant antigen TB10.4 and the two homologous proteins TB10.3 and TB12.9, which constitute a subfamily of the esat-6 gene family. Infect. Immun. 2002

Interaction

Regulatory Rv3019c

ilamathi.raja

IEP

Co-expression (Functional linkage)
A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009

Interaction

Regulatory Rv3020c

ilamathi.raja

IEP

Interaction

Regulatory Rv3017c

ilamathi.raja

IEP

Interaction

Regulatory Rv3017c

ilamathi.raja

IEP

Co-expression (Functional linkage)
A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009

Interaction

Regulatory Rv3017c

ilamathi.raja

IEP

Co-expression (Functional linkage)
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Transcription Rv2358

jhum4u2006

IPI

Affinity purification (Physical interaction)
F. Canneva, M. Branzoni et al. Rv2358 and FurB: two transcriptional regulators from Mycobacterium tuberculosis which respond to zinc. J. Bacteriol. 2005

Citation

Rv2358 and FurB: two transcriptional regulators from Mycobacterium tuberculosis which respond to zinc. F. Canneva, M. Branzoni et al. J. Bacteriol. 2005

jhum4u2006

IPI

16077132

Affinity purification (Physical interaction)

Interaction

Transcription Rv2358

jhum4u2006

IPI

Affinity purification (Physical interaction)
F. Canneva, M. Branzoni et al. Rv2358 and FurB: two transcriptional regulators from Mycobacterium tuberculosis which respond to zinc. J. Bacteriol. 2005

Interaction

PhysicalInteraction Rv2057c

devensrcp

IEP

Physical interaction
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

PhysicalInteraction Rv2058c

shahanup86

IEP

Physical interaction
authors,GA. Owen,B. Pascoe,D. Kallifidas,MS. Paget Zinc-responsive regulation of alternative ribosomal protein genes in Streptomyces coelicolor involves zur and sigmaR. J. Bacteriol. 2007

Interaction

PhysicalInteraction Rv2058c

shahanup86

IEP

Physical interaction
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Regulatory Rv2059

shahanup86

IDA

Co-expression (Functional linkage)
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Regulates Rv2055c

akankshajain.21

IEP

Co-expression (Functional linkage)
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

PhysicalInteraction Rv2056c

devensrcp

IEP

ChiP (Physical Interaction)
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

PhysicalInteraction Rv2056c

devensrcp

IEP

ChiP (Physical Interaction)
authors,GA. Owen,B. Pascoe,D. Kallifidas,MS. Paget Zinc-responsive regulation of alternative ribosomal protein genes in Streptomyces coelicolor involves zur and sigmaR. J. Bacteriol. 2007

Interaction

PhysicalInteraction Rv2057c

devensrcp

IEP

Physical interaction
authors,DJ. Beste,E. Laing,B. Bonde,C. Avignone-Rossa,ME. Bushell,JJ. McFadden Transcriptomic analysis identifies growth rate modulation as a component of the adaptation of mycobacteria to survival inside the macrophage. J. Bacteriol. 2007

Interaction

Transcription Rv1195

ahal4789

IDA

Band shift
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Transcription Rv1195

ahal4789

IDA

Band shift
S. Denkin, S. Byrne et al. Gene expression profiling analysis of Mycobacterium tuberculosis genes in response to salicylate. Arch. Microbiol. 2005

Interaction

Regulatory Rv0634B

prabhakarsmail

ISO

Footprinting
authors,GA. Owen,B. Pascoe,D. Kallifidas,MS. Paget Zinc-responsive regulation of alternative ribosomal protein genes in Streptomyces coelicolor involves zur and sigmaR. J. Bacteriol. 2007

Interaction

Regulatory Rv0634B

prabhakarsmail

ISO

Footprinting
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Regulatory Rv0634B

akankshajain.21

ISO

Footprinting
authors,JH. Shin,SY. Oh,SJ. Kim,JH. Roe The zinc-responsive regulator Zur controls a zinc uptake system and some ribosomal proteins in Streptomyces coelicolor A3(2). J. Bacteriol. 2007

Interaction

Regulatory Rv0634B

akankshajain.21

ISO

Interaction

Regulatory Rv0634B

akankshajain.21

ISO

Footprinting
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Regulatory Rv0634B

prabhakarsmail

ISO

Footprinting
authors,JH. Shin,SY. Oh,SJ. Kim,JH. Roe The zinc-responsive regulator Zur controls a zinc uptake system and some ribosomal proteins in Streptomyces coelicolor A3(2). J. Bacteriol. 2007

Interaction

Regulatory Rv0292

gaat3s

IGC

Gene Neighborhood (Functional linkage)
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Regulatory Rv0290

gaat3s

IGC

Gene Neighborhood (Functional linkage)
A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009

Interaction

Regulatory Rv0290

gaat3s

IGC

Gene Neighborhood (Functional linkage)
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Regulatory Rv0292

gaat3s

IGC

Gene Neighborhood (Functional linkage)
A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009

Interaction

Regulatory Rv0289

gaat3s

IGC

Gene Neighborhood (Functional linkage)
A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009

Interaction

Regulatory Rv0289

gaat3s

IGC

Gene Neighborhood (Functional linkage)
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Regulatory Rv0284

gaat3s

IGC

Gene Neighborhood (Functional linkage)
GM. Rodriguez, MI. Voskuil et al. ideR, An essential gene in mycobacterium tuberculosis: role of IdeR in iron-dependent gene expression, iron metabolism, and oxidative stress response. Infect. Immun. 2002

Interaction

Regulatory Rv0284

gaat3s

IGC

Gene Neighborhood (Functional linkage)
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Regulatory Rv0283

gaat3s

IGC

Interaction

Regulatory Rv0283

gaat3s

IGC

Gene Neighborhood (Functional linkage)
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Regulatory Rv0284

gaat3s

IGC

Gene Neighborhood (Functional linkage)
A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009

Interaction

Regulatory Rv0282

gaat3s

IDA

Band Shift
A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009

Interaction

Regulatory Rv0283

gaat3s

IGC

Gene Neighborhood (Functional linkage)
A. Maciag, A. Piazza et al. Transcriptional analysis of ESAT-6 cluster 3 in Mycobacterium smegmatis. BMC Microbiol. 2009

Interaction

Regulatory Rv0105c

akankshajain.21

IDA

Footprinting
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Regulatory Rv0105c

prabhakarsmail

IDA

Footprinting
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

RegulatedBy Rv2358

yamir.moreno

IDA

Electrophoretic mobility shift assays EMSA. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . LacZ-promoter fusion. expression levels of LacZ- regulated promoter fusion measured and compared between wild-type and trans-element mutation (knockout, over expression etc.).
F. Canneva, M. Branzoni et al. Rv2358 and FurB: two transcriptional regulators from Mycobacterium tuberculosis which respond to zinc. J. Bacteriol. 2005

Interaction

RegulatedBy Rv2358

yamir.moreno

IEP

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv3612c

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv2990c

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv3020c

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv3022c

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv3229c

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

Regulates Rv2055c

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv2056c

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv2057c

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv2060

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. qRT-PCR. mRNA expression levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using qRT-PCR technique.

Interaction

Regulates Rv1857

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. qRT-PCR. mRNA expression levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using qRT-PCR technique.
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. qRT-PCR. mRNA expression levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using qRT-PCR technique.

Interaction

Regulates Rv1857

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments.. qRT-PCR. mRNA expression levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using qRT-PCR technique.
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv1870c

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0290

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0291

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0292

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv1195

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0287

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0288

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0289

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0283

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0284

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0285

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0286

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0232

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Citation

Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. A. Maciag, E. Dainese et al. J. Bacteriol. 2007

yamir.moreno

IEP

17098899

Interaction

Regulates Rv0281

yamir.moreno

IEP

Microarrays. mRNA levels of regulated element measured and compared between wild-type and trans-element mutation (knockout, over expression etc.) performed by using microarray (or macroarray) experiments..
A. Maciag, E. Dainese et al. Global analysis of the Mycobacterium tuberculosis Zur (FurB) regulon. J. Bacteriol. 2007

Interaction

RegulatedBy Rv3676

yamir.moreno

ISO

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008

Interaction

Regulates Rv3022c

yamir.moreno

TAS

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.
G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv3215

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv3229c

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv3612c

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv3846

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv2990c

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv3017c

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv3019c

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv3020c

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv2060

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv2359

yamir.moreno

ISO

Interaction

RegulatedBy Rv2359

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv2384

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv2794c

yamir.moreno

ISO

Interaction

Regulates Rv2055c

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv2056c

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv2057c

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv2058c

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv2059

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv1857

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv1870c

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1928c

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1945

yamir.moreno

ISO

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0291

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0292

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv1195

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1847

yamir.moreno

ISO

Interaction

Regulates Rv0286

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0287

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0288

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0289

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0290

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0282

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0283

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0284

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0285

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0106

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0232

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0280

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0281

yamir.moreno

TAS

Interaction

RegulatedBy Rv2358

yamir.moreno

TAS

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

TAS

18985025

Literature previously reported link (from Balazsi et al. 2008). Traceable author statement to experimental support.

Interaction

Regulates Rv0105c

yamir.moreno

TAS

Interaction

RegulatedBy Rv3676

yamir.moreno

ISO

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006

Interaction

Regulates Rv3215

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv3846

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1945

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv2359

yamir.moreno

ISO

Interaction

RegulatedBy Rv2359

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv2384

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv2794c

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1847

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1928c

yamir.moreno

ISO

Comments
