Rv1956 (higA)

Current annotations:
- TBCAP: (community-based annotations - see table at bottom of page)
- TBDB: antitoxin transcriptional regulator
- REFSEQ: transcriptional regulatory protein
- PATRIC: Possible transcriptional regulatory protein
- TUBERCULIST: Possible antitoxin HigA
- NCBI: Possible antitoxin HigA
- updated information (H37Rv4):
  - gene name: higA
  - function:
  - reference:
Type: Not Target
Start: 2202138
End: 2202587
Operon:

Trans-membrane region:
Role: I.J.1 - Repressors/activators
GO terms:
- GO:0045927 - positive regulation of growth (Uniprot)
- GO:0045926 - negative regulation of growth (Uniprot)
- GO:0045892 - negative regulation of transcription, DNA-templated (Uniprot)
- GO:0043565 - sequence-specific DNA binding (Uniprot)
- GO:0019217 - regulation of fatty acid metabolic process (Uniprot)
- GO:0006355 - regulation of transcription, DNA-templated (Uniprot)
- GO:0006351 - transcription, DNA-templated (Uniprot)
- GO:0005515 - protein binding (Uniprot)
- GO:0003677 - DNA binding (Uniprot)
- GO:0001666 - response to hypoxia (Uniprot)
Reaction(s) (based on iSM810 metabolic model):
Gene Expression Profile (Transcriptional Responses to Drugs; Boshoff et al, 2004)
Gene Modules extracted from cluster analysis of 249 transcriptomic datasets using ICA
Orthologs among selected mycobacteria
Protein structure:
Search for Homologs in PDB
Top 10 Homologs in PDB (as of Nov 2020): (none with >35% aa id)
Links to additional information on higA:
- TBDB (updated)
- Phyre2 structure prediction, model: final.casp.pdb (from Mao et al, 2013)
- UniProt
- AlphaFold model
- Vulnerability = -2.212 (from Jeremy Rock's lab)
- KEGG - nucleotide and amino acid sequences of gene
- Mycobrowser
- PATRIC
- BioCyc
- Systems Biology

Amino Acid Sequence

MSIDFPLGDDLAGYIAEAIAADPSFKGTLEDAEEARRLVDALIALRKHCQLSQVEVAKRMGVRQPTVSGFEKEPSDPKLSTLQRYARALDARLRLVLEVP
TLREVPTWHRLSSYRGSARDHQVRVGADKEILMQTNWARHISVRQVEVA

(Nucleotide sequence available on KEGG)

Additional Information

ESSENTIALITY

MtbTnDB - interactive tool for exploring a database of published TnSeq datasets for Mtb

TnSeqCorr - genes with correlated TnSeq profiles across >100 conditions *new*

Classification	Condition	Strain	Method	Reference	Notes
Non-Essential	Sodium Oleate	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 8 sites
Non-Essential	Lignoceric Acid	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 8 sites
Non-Essential	Phosphatidylcholine	H37RvMA	Gumbel	Subhalaxmi Nambi	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 8 sites
Non-Essential	minimal media + 0.1% glycerol	H37RvMA	Gumbel	Griffin et al. (2011)	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 8 sites
Non-Essential	minimal media + 0.01% cholesterol	H37RvMA	Gumbel	Griffin et al. (2011)	Probability of Essentiality: 0.000000; 2 non-insertions in a row out of 8 sites
Non-Essential	7H10-glycerol	H37RvMA	TraSH	Sassetti et al. (2003a)
Non-Essential	C57BL/6J mice (8 weeks)	H37RvMA	TraSH	Sassetti et al. (2003b)	Hybridization Ratio: 0.77
Growth-Advantage	7H09/7H10 + rich media	H37RvMA	MotifHMM	DeJesus et al. (2017)	Fully saturated (14 reps).

TnSeq Data No data currently available.

No TnSeq data currently available for this Target.

RNASeq Data No data currently available.

No RNA-Seq data currently available for this Target.

Metabolomic Profiles No data currently available.

No Metabolomic data currently available for this Target.

Proteomic Data No data currently available.

No Proteomic data currently available for this Target.

Regulatory Relationships from Systems Biology

BioCyc

Gene interactions based on ChIPSeq and Transcription Factor Over-Expression (TFOE) (Systems Biology)

NOTE: Green edges represent the connected genes being classified as differentially essential as a result of the middle gene being knocked out. These interactions are inferred based on RNASeq.

Interactions based on ChIPSeq data

Interactions based on ChIPSeq data (Minch et al. 2014)

Binds To:
- Rv0147 (-) (Direct binding)
- Rv0509 (hemA) (Direct binding)
- Rv0610c (-) (Direct binding)
- Rv0611c (-) (Direct binding)
- Rv0824c (desA1) (Direct binding)
- Rv0904c (accD3) (Direct binding)
- Rv0905 (echA6) (Direct binding)
- Rv1247c (relB) (Direct binding)
- Rv1313c (-) (Direct binding)
- Rv1503c (-) (Direct binding)
- Rv1636 (TB15.3) (Direct binding)
- Rv1786 (-) (Direct binding)
- Rv1842c (-) (Direct binding)
- Rv1952 (vapB14) (Direct binding)
- Rv1953 (vapC14) (Direct binding)
- Rv1954c (-) (Direct binding)
- Rv1964 (yrbE3A) (Direct binding)
- Rv2194 (qcrC) (Direct binding)
- Rv2219A (-) (Direct binding)
- Rv2220 (glnA1) (Direct binding)
- Rv2349c (plcC) (Direct binding)
- Rv2636 (-) (Direct binding)
- Rv2787 (-) (Direct binding)
- Rv2859c (-) (Direct binding)
- Rv3083 (-) (Direct binding)
- Rv3182 (-) (Direct binding)
- Rv3738c (PPE66) (Direct binding)
- Rv3780 (-) (Direct binding)
- Rv0510 (hemC) (Upstream of operon)
- Rv0511 (hemD) (Upstream of operon)
- Rv0906 (-) (Upstream of operon)
- Rv1246c (relE) (Upstream of operon)
- Rv1841c (-) (Upstream of operon)
- Rv1965 (yrbE3B) (Upstream of operon)
- Rv1966 (mce3A) (Upstream of operon)
- Rv1967 (mce3B) (Upstream of operon)
- Rv1968 (mce3C) (Upstream of operon)
- Rv1969 (mce3D) (Upstream of operon)
- Rv1970 (lprM) (Upstream of operon)
- Rv1971 (mce3F) (Upstream of operon)
- Rv1972 (-) (Upstream of operon)
- Rv1973 (-) (Upstream of operon)
- Rv1974 (-) (Upstream of operon)
- Rv1975 (-) (Upstream of operon)
- Rv2195 (qcrA) (Upstream of operon)
- Rv2196 (qcrB) (Upstream of operon)
- Rv3084 (lipR) (Upstream of operon)
- Rv3085 (-) (Upstream of operon)
- Rv3086 (adhD) (Upstream of operon)
- Rv3087 (-) (Upstream of operon)
- Rv3088 (tgs4) (Upstream of operon)
- Rv3089 (fadD13) (Upstream of operon)
- Rv3183 (-) (Upstream of operon)
Bound By:
- No bindings to other targets were found.

Interactions based on TFOE data (Rustad et al. 2014)

Upregulates:
- Rv1956 (higA)
Upregulated by:
Downregulates:
- Rv1954c (-)
- Rv3409c (choD)
Downregulated by:

TBCAP

Tubculosis Community Annotation Project (

Slayden et al., 2013

Rv1956 (higA)

Property	Value	Creator	Evidence	PMID	Comment
Interaction	Inhibits Rv1955	akankshajain.21	IDA		Spectrophotometric analysis authors,A. Gupta Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. FEMS Microbiol. Lett. 2009
Interaction	Inhibits Rv1955	prabhakarsmail	IDA		Spectrophotometric analysis authors,A. Gupta Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. FEMS Microbiol. Lett. 2009
Citation	Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. authors,A. Gupta FEMS Microbiol. Lett. 2009	akankshajain.21	IDA	19016878	Spectrophotometric analysis
Interaction	Inhibits Rv1955	akankshajain.21	IDA		Spectrophotometric analysis authors,A. Gupta Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. FEMS Microbiol. Lett. 2009
Citation	Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. authors,A. Gupta FEMS Microbiol. Lett. 2009	prabhakarsmail	IDA	19016878	Spectrophotometric analysis
Interaction	Inhibits Rv1955	prabhakarsmail	IDA		Spectrophotometric analysis authors,A. Gupta Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. FEMS Microbiol. Lett. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3545c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3550	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3551	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3552	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3537	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3538	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3543c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3544c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3249c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3250c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3251c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3252c	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2937	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2938	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2939	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv3197A	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2933	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2934	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2935	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2936	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2930	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2931	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009	yamir.moreno	IDA	19228590	One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
Interaction	Regulates Rv2932	yamir.moreno	IDA		One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. . M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009
Citation	The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008	yamir.moreno	ISO	18985025	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1956	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Interaction	RegulatedBy Rv1956	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008
Citation	Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006	yamir.moreno	ISO	16530225	E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
Interaction	Regulates Rv1956	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Interaction	RegulatedBy Rv1956	yamir.moreno	ISO		E.coli orthology based inference. Orthologous pair regulator-target found in E.coli. authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006
Symbol	higA	jlew			Pulldown shows interaction between Rv1957 and HigA. authors,P. Bordes,AM. Cirinesi,R. Ummels,A. Sala,S. Sakr,W. Bitter,P. Genevaux SecB-like chaperone controls a toxin-antitoxin stress-responsive system in Mycobacterium tuberculosis. Proc. Natl. Acad. Sci. U.S.A. 2011
Citation	SecB-like chaperone controls a toxin-antitoxin stress-responsive system in Mycobacterium tuberculosis. authors,P. Bordes,AM. Cirinesi,R. Ummels,A. Sala,S. Sakr,W. Bitter,P. Genevaux Proc. Natl. Acad. Sci. U.S.A. 2011	jlew		21536872	Pulldown shows interaction between Rv1957 and HigA.
Symbol	higA	jlew			binds to promoter upstream of Rv1954A authors,AS. Fivian-Hughes,EO. Davis Analyzing the regulatory role of the HigA antitoxin within Mycobacterium tuberculosis. J. Bacteriol. 2010
Citation	Analyzing the regulatory role of the HigA antitoxin within Mycobacterium tuberculosis. authors,AS. Fivian-Hughes,EO. Davis J. Bacteriol. 2010	jlew		20585061	binds to promoter upstream of Rv1954A
Symbol	HigB1	jlew			Toxic to Ecoli growth. We report the heterologous toxicity of these TA loci in Escherichia coli and show that only a few of the M. tuberculosis-encoded toxins can inhibit E. coli growth and have a killing effect. This killing effect can be suppressed by coexpression of the cognate antitoxin. authors,A. Gupta Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. FEMS Microbiol. Lett. 2009
Citation	Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. authors,A. Gupta FEMS Microbiol. Lett. 2009	jlew		19016878	Toxic to Ecoli growth. We report the heterologous toxicity of these TA loci in Escherichia coli and show that only a few of the M. tuberculosis-encoded toxins can inhibit E. coli growth and have a killing effect. This killing effect can be suppressed by coexpression of the cognate antitoxin.
Symbol	Hig BA-1	rslayden			Possible transcriptional regulatory protein, contains probable helix-turn-helix motif at aa 52-73 (+4.78 SD).
Other	start:2202138	rslayden			Possible transcriptional regulatory protein, contains probable helix-turn-helix motif at aa 52-73 (+4.78 SD).
Other	stop:2202587	rslayden			Possible transcriptional regulatory protein, contains probable helix-turn-helix motif at aa 52-73 (+4.78 SD).
Other	strand:+	rslayden			Possible transcriptional regulatory protein, contains probable helix-turn-helix motif at aa 52-73 (+4.78 SD).

Property

Value

Creator

Evidence

PMID

Comment

Interaction

Inhibits Rv1955

akankshajain.21

IDA

Spectrophotometric analysis
authors,A. Gupta Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. FEMS Microbiol. Lett. 2009

Interaction

Inhibits Rv1955

prabhakarsmail

IDA

Spectrophotometric analysis
authors,A. Gupta Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. FEMS Microbiol. Lett. 2009

Citation

Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. authors,A. Gupta FEMS Microbiol. Lett. 2009

akankshajain.21

IDA

19016878

Spectrophotometric analysis

Interaction

Inhibits Rv1955

akankshajain.21

IDA

Spectrophotometric analysis
authors,A. Gupta Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. FEMS Microbiol. Lett. 2009

Citation

Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. authors,A. Gupta FEMS Microbiol. Lett. 2009

prabhakarsmail

IDA

19016878

Spectrophotometric analysis

Interaction

Inhibits Rv1955

prabhakarsmail

IDA

Spectrophotometric analysis
authors,A. Gupta Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. FEMS Microbiol. Lett. 2009

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3545c

yamir.moreno

IDA

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .
M. Guo, H. Feng et al. Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. Genome Res. 2009

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3550

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3551

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3552

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3537

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3538

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3543c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3544c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3249c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3250c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3251c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3252c

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2937

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2938

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2939

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv3197A

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2933

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2934

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2935

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2936

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2930

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2931

yamir.moreno

IDA

Citation

Dissecting transcription regulatory pathways through a new bacterial one-hybrid reporter system. M. Guo, H. Feng et al. Genome Res. 2009

yamir.moreno

IDA

19228590

One hybrid reporter system. Physical binding of the regulator to the regulated promoter proved by using electrophoretic mobility shift assay. .

Interaction

Regulates Rv2932

yamir.moreno

IDA

Citation

The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. G. Balzsi, AP. Heath et al. Mol. Syst. Biol. 2008

yamir.moreno

ISO

18985025

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1956

yamir.moreno

ISO

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
G. Balzsi, AP. Heath et al. The temporal response of the Mycobacterium tuberculosis gene regulatory network during growth arrest. Mol. Syst. Biol. 2008

Interaction

RegulatedBy Rv1956

yamir.moreno

ISO

Citation

Evolutionary dynamics of prokaryotic transcriptional regulatory networks. authors,M. Madan Babu,SA. Teichmann,L. Aravind J. Mol. Biol. 2006

yamir.moreno

ISO

16530225

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.

Interaction

Regulates Rv1956

yamir.moreno

ISO

E.coli orthology based inference. Orthologous pair regulator-target found in E.coli.
authors,M. Madan Babu,SA. Teichmann,L. Aravind Evolutionary dynamics of prokaryotic transcriptional regulatory networks. J. Mol. Biol. 2006

Interaction

RegulatedBy Rv1956

yamir.moreno

ISO

Symbol

higA

jlew

Pulldown shows interaction between Rv1957 and HigA.
authors,P. Bordes,AM. Cirinesi,R. Ummels,A. Sala,S. Sakr,W. Bitter,P. Genevaux SecB-like chaperone controls a toxin-antitoxin stress-responsive system in Mycobacterium tuberculosis. Proc. Natl. Acad. Sci. U.S.A. 2011

Citation

SecB-like chaperone controls a toxin-antitoxin stress-responsive system in Mycobacterium tuberculosis. authors,P. Bordes,AM. Cirinesi,R. Ummels,A. Sala,S. Sakr,W. Bitter,P. Genevaux Proc. Natl. Acad. Sci. U.S.A. 2011

jlew

21536872

Pulldown shows interaction between Rv1957 and HigA.

Symbol

higA

jlew

binds to promoter upstream of Rv1954A
authors,AS. Fivian-Hughes,EO. Davis Analyzing the regulatory role of the HigA antitoxin within Mycobacterium tuberculosis. J. Bacteriol. 2010

Citation

Analyzing the regulatory role of the HigA antitoxin within Mycobacterium tuberculosis. authors,AS. Fivian-Hughes,EO. Davis J. Bacteriol. 2010

jlew

20585061

binds to promoter upstream of Rv1954A

Symbol

HigB1

jlew

Toxic to Ecoli growth. We report the heterologous toxicity of these TA loci in Escherichia coli and show that only a few of the M. tuberculosis-encoded toxins can inhibit E. coli growth and have a killing effect. This killing effect can be suppressed by coexpression of the cognate antitoxin.
authors,A. Gupta Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. FEMS Microbiol. Lett. 2009

Citation

Killing activity and rescue function of genome-wide toxin-antitoxin loci of Mycobacterium tuberculosis. authors,A. Gupta FEMS Microbiol. Lett. 2009

jlew

19016878

Symbol

Hig BA-1

rslayden

Possible transcriptional regulatory protein, contains probable helix-turn-helix motif at aa 52-73 (+4.78 SD).

Other

start:2202138

rslayden

Possible transcriptional regulatory protein, contains probable helix-turn-helix motif at aa 52-73 (+4.78 SD).

Other

stop:2202587

rslayden

Possible transcriptional regulatory protein, contains probable helix-turn-helix motif at aa 52-73 (+4.78 SD).

Other

strand:+

rslayden

Possible transcriptional regulatory protein, contains probable helix-turn-helix motif at aa 52-73 (+4.78 SD).

Comments
